PMPB20XNEAZ Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DFN2020MD-6
- Description: MOSFET N-CH 20V 7.5A DFN2020MD-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMPB20XNEAZ Specifications:
- MfrPart.: PMPB20XNEAZ
- Mfr: Nexperia USA Inc.
- Description: MOSFET N-CH 20V 7.5A DFN2020MD-6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 7.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 20mOhm @ 7.5A, 4.5V
- Vgs(th)(Max)@Id: 1.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 15 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 930 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 460mW (Ta), 12.5W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DFN2020MD-6
- PMPB20XNEAZ Nexperia(NXP), MOSFET N-CH 20V 7.5A DFN2020MD-6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
