PMN42XPEAH Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-TSOP
- Description: MOSFET P-CH 20V 5.7A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMN42XPEAH Specifications:
- MfrPart.: PMN42XPEAH
- Mfr: Nexperia USA Inc.
- Description: MOSFET P-CH 20V 5.7A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, TrenchMOS™
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 5.7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 46mOhm @ 3A, 4.5V
- Vgs(th)(Max)@Id: 1.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 17.3 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 1410 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 500mW (Ta), 8.33W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-TSOP
- PMN42XPEAH Nexperia(NXP), MOSFET P-CH 20V 5.7A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMN42XPEAH, Nexperia authentic parts in stock from Nexperia(NXP) authorized distributors, order today, can ship immediately.
