BSS138BKW-BX Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-323
- Description: MOSFET N-CHANNEL 60V 320MA SC70
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSS138BKW-BX Specifications:
- MfrPart.: BSS138BKW-BX
- Mfr: Nexperia USA Inc.
- Description: MOSFET N-CHANNEL 60V 320MA SC70
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 320mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 10V
- RdsOn(Max)@IdVgs: 1.6Ohm @ 320mA, 10V
- Vgs(th)(Max)@Id: 1.6V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 0.7 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 56 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 830mW (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-323
- BSS138BKW-BX Nexperia(NXP), MOSFET N-CHANNEL 60V 320MA SC70, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
