BAV170QAZ Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: 3-XDFN Exposed Pad
- Description: DIODE HS SW 75V 180MA 3DFN1010
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAV170QAZ Specifications:
- Mfr Part: BAV170QAZ
- Mfr: Nexperia USA Inc.
- Description: DIODE HS SW 75V 180MA 3DFN1010
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- Part Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 75 V
- Current - Average Rectified (Io) (per Diode): 180mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 5 nA @ 75 V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: 3-XDFN Exposed Pad
- BAV170QAZ Nexperia(NXP), DIODE HS SW 75V 180MA 3DFN1010, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
BAV170QAZ, Nexperia authentic parts in stock from Nexperia(NXP) authorized distributors, order today, can ship immediately.
